Engine Model: AUCAN 2.0L Turbo Diesel Hybrid Engine

Engine Type: Diesel Engine 4-cylinder In-line w/ 16 Valve DOHC, Electronically Controlled Highpressure
Common-rail Direct Injection, BorgWarner VGT w/ WCAC, Water-cooling +
48V Boost Recuperation System (BRS)

Displacement (cc): 1,968

Maximum Power (Hp/rpm): 161 / 3,600

Maximum Torque (N.m/rpm): 450 / 1,500 - 2,600

Emission Standard: Euro V

Transmission: ZF 8 Speed AT

Overall Dimensions LxWxH (mm): 5,617 x 2,090 x 1,910

Cargo Bed LxWxH (mm): 1,577 x 1,650 x 530

Wheelbase (mm): 3,355

Gross Vehicle Weight (kg): 3,055

Payload (kg): 875

Seating Capacity: 5 seater

Minimum Ground Clearance (mm): 240

Maximum Wading Depth (mm): 700

Tires: 265/70R18 Alloy Wheels 265/70R18 Alloy Wheels w/ AT Tires

Front Suspension: Front double wishbone independent suspension

Rear Suspension: Rear five-link + Coil spring integrated axle suspension

Steering System: Electronic Power Steering (EPS)

Fuel Tank Capacity (L): 76

Brake Front: Ventilated Disc brake w/ ABS + EBD

Brake Rear: Ventilated Disc brake w/ ABS + EBD

Battery - Low Voltage (v): 12

Infotainment: 14.6 inch Carbit link wireless mobile phone interconnection + Bluetooth Audio
Streaming + USB + Tuner + 6 speakers

Safety & Security

4x2
6 Airbags (Driver, Front Passenger, Front
side & Side Curtain), Reverse Camera and
Radar, ESP-Electronic Stability Program
(Anti-Lock Brake System [ABS], Electronic
Braking Force Distribution [EBD], Vehicle
Dynamics Control [VDC], Traction Control
System [TCS], Hydraulic Brake Assist
[HBA], Hill-Start Hold Control [HHC], Hill
Descent Control [HDC], Hydraulic Brake
Boost [HBB], Brake Lamp Flasher [BLF]) +
Tire Pressure Monitoring System [TPMS],
Fatigue Driving Reminder, Cruise Control,
Adjustable Speed Limit Control

4x4
6 Airbags (Driver, Front Passenger,
Reverse Camera and Radar, Front side
& Side Curtain), ESP-Electronic Stability
Program (Anti-Lock Brake System
[ABS], Electronic Braking Force
Distribution [EBD], Vehicle Dynamics
Control [VDC], Traction Control System
[TCS], Hydraulic Brake Assist [HBA],
Hill-Start Hold Control [HHC], Hill
Descent Control [HDC], Hydraulic Brake
Boost [HBB], Brake Lamp Flasher [BLF])
+ Tire Pressure Monitoring System
[TPMS], Fatigue Driving Reminder,
Cruise Control, Adjustable Speed Limit
Control, Differential Lock

Comfort and Convenience:

4x2
Keyless Entry with Hold Window Down
Control, Power Window Control, Central
Locking System, Power Side Mirrors,
Multi-function steering wheel, Electronic
Driver Seat 8-way adjustment +
Electronic Front Passenger 4-way
adjustment, Wireless Charger, 12.3 inch
Analog + LCD instrument (display
navigation/system
information/ACC/bluetooth/
entertainment information)

4x4
Keyless Entry with Hold Window Down
Control, Power Window Control,
Central Locking System, Power Side
Mirrors, Multi-function steering wheel,
Electronic Driver Seat 8-way
adjustment + Electronic Front
Passenger 4-way adjustment, Wireless
Charger, 12.3 inch Analog + LCD
instrument (display navigation/system
information/ACC/bluetooth/
entertainment information)

Exterior Features: Spray On Bed Liner, Inner Tie Downs, Off-road Side Step, Overfenders,
Tail Gate Steps
