Engine Model: AUCAN 4F20 + BOSCH 48V Hybrid System
Engine Type : Diesel Engine 4-cylinder In-line w/ 16 Valve DOHC, Electronically Controlled Highpressure
Common-rail Direct Injection, BorgWarner VGT w/ WCAC, Water-cooling +
48V Boost Recuperation System (BRS)
Displacement (cc): 1,968
Maximum Power (Hp/rpm): 161 / 3,600
Maximum Torque (N.m/rpm): 450 / 1,500 - 2,600
Emission Standard: Euro V
Transmission: ZF 8 Speed AT
Overall Dimensions LxWxH (mm): 5,617 x 2,090 x 1,910
Cargo Bed LxWxH (mm): 1,577 x 1,650 x 530
Wheelbase (mm): 3355
Gross Vehicle Weight (kg): 3055
Payload (kg): 875
Seating Capacity: 5 seater
Minimum Ground Clearance (mm): 240
Maximum Wading Depth (mm): 700
Tires: 265/70R18 Alloy Wheels 265/70R18 Alloy Wheels w/ AT Tires
Front Suspension: Front double wishbone independent suspension
Rear Suspension: Rear leaf spring non independent suspension
Steering System: Hydraulic Power Steering
Fuel Tank Capacity (L): 76
Brake Front: Ventilated Disc brake w/ ABS + EBD
Brake Rear: Ventilated Disc brake w/ ABS + EBD
Battery - Low Voltage (v): 12
Infotainment: 14.6 inch Carbit link wireless mobile phone interconnection + Bluetooth Audio
Streaming + USB + Tuner + 4 speakers
Safety & Security: 2 Airbags (Driver & Front Passenger), Reverse Camera and Radar, ESP-Electronic
Stability Program (Anti-Lock Brake System [ABS], Electronic Braking Force
Distribution [EBD], Vehicle Dynamics Control [VDC], Traction Control System [TCS],
Hydraulic Brake Assist [HBA], Hill-Start Hold Control [HHC], Hill Descent Control
[HDC], Hydraulic Brake Boost [HBB], Brake Lamp Flasher [BLF]) + Tire Pressure
Monitoring System [TPMS], Fatigue Driving Reminder, Cruise Control, Adjustable
Speed Limit Control
Comfort and Convenience:
4x2
Keyless Entry with Hold Window Down
Control, Power Window Control,
Central Locking System, Power Side
Mirrors, Multi-function steering wheel,
Electronic Driver Seat 8-way
adjustment, 12.3 inch Analog + LCD
instrument (display navigation/system
information/ACC/bluetooth/
entertainment information)
4x4
Keyless Entry with Hold Window Down
Control, Power Window Control, Central
Locking System, Power Side Mirrors,
Multi-function steering wheel, Electronic
Driver Seat 8-way adjustment, 12.3 inch
Analog + LCD instrument (display
navigation/system
information/ACC/bluetooth/
entertainment information)
Exterior Features: Spray On Bed Liner, Inner Tie Downs, Side Step
Engine Type : Diesel Engine 4-cylinder In-line w/ 16 Valve DOHC, Electronically Controlled Highpressure
Common-rail Direct Injection, BorgWarner VGT w/ WCAC, Water-cooling +
48V Boost Recuperation System (BRS)
Displacement (cc): 1,968
Maximum Power (Hp/rpm): 161 / 3,600
Maximum Torque (N.m/rpm): 450 / 1,500 - 2,600
Emission Standard: Euro V
Transmission: ZF 8 Speed AT
Overall Dimensions LxWxH (mm): 5,617 x 2,090 x 1,910
Cargo Bed LxWxH (mm): 1,577 x 1,650 x 530
Wheelbase (mm): 3355
Gross Vehicle Weight (kg): 3055
Payload (kg): 875
Seating Capacity: 5 seater
Minimum Ground Clearance (mm): 240
Maximum Wading Depth (mm): 700
Tires: 265/70R18 Alloy Wheels 265/70R18 Alloy Wheels w/ AT Tires
Front Suspension: Front double wishbone independent suspension
Rear Suspension: Rear leaf spring non independent suspension
Steering System: Hydraulic Power Steering
Fuel Tank Capacity (L): 76
Brake Front: Ventilated Disc brake w/ ABS + EBD
Brake Rear: Ventilated Disc brake w/ ABS + EBD
Battery - Low Voltage (v): 12
Infotainment: 14.6 inch Carbit link wireless mobile phone interconnection + Bluetooth Audio
Streaming + USB + Tuner + 4 speakers
Safety & Security: 2 Airbags (Driver & Front Passenger), Reverse Camera and Radar, ESP-Electronic
Stability Program (Anti-Lock Brake System [ABS], Electronic Braking Force
Distribution [EBD], Vehicle Dynamics Control [VDC], Traction Control System [TCS],
Hydraulic Brake Assist [HBA], Hill-Start Hold Control [HHC], Hill Descent Control
[HDC], Hydraulic Brake Boost [HBB], Brake Lamp Flasher [BLF]) + Tire Pressure
Monitoring System [TPMS], Fatigue Driving Reminder, Cruise Control, Adjustable
Speed Limit Control
Comfort and Convenience:
4x2
Keyless Entry with Hold Window Down
Control, Power Window Control,
Central Locking System, Power Side
Mirrors, Multi-function steering wheel,
Electronic Driver Seat 8-way
adjustment, 12.3 inch Analog + LCD
instrument (display navigation/system
information/ACC/bluetooth/
entertainment information)
4x4
Keyless Entry with Hold Window Down
Control, Power Window Control, Central
Locking System, Power Side Mirrors,
Multi-function steering wheel, Electronic
Driver Seat 8-way adjustment, 12.3 inch
Analog + LCD instrument (display
navigation/system
information/ACC/bluetooth/
entertainment information)
Exterior Features: Spray On Bed Liner, Inner Tie Downs, Side Step
